Associated Spring Raymond - 9.14mm OD, 48.91 N Max Load, 69.85mm Max Ext Len, Stainless Steel Extension Spring - 10 Lb/In Rating, 1 Lb Init Tension, 44.45mm Free Length
Item #: 69116978
Brand: Associated Spring Raymond
Model #: E03600491750S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Stainless Steel |
| Spring Rate Pounds per Inch (Pounds) | 10.0000 |
| Initial Tension (N) | 4.44999981 |
| Initial Tension (Lb.) | 1 |
| Free Length (mm) | 44.45 |
| Free Length (Decimal Inch) | 1-3/4 |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Maximum Work Load (N) | 48.90999985 |
| Maximum Extended Length (mm) | 69.85 |
| Maximum Extended Length (Decimal Inch) | 2-3/4 |
