![Associated Spring Raymond - 16.51mm OD, 44.93 N Max Load, 56.13mm Max Ext Len, Music Wire Extension Spring - 13.4 Lb/In Rating, 0.9 Lb Init Tension, 38.1mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909853-21_6631729b-920d-4cac-9edb-ab9a158ce1ff_1024x1024.jpg?v=1586245819)
Associated Spring Raymond - 16.51mm OD, 44.93 N Max Load, 56.13mm Max Ext Len, Music Wire Extension Spring - 13.4 Lb/In Rating, 0.9 Lb Init Tension, 38.1mm Free Length
Item #: 69111623
Brand: Associated Spring Raymond
Model #: E06500551500M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 13.4000 |
Initial Tension (N) | 4 |
Initial Tension (Lb.) | 0.89999998 |
Free Length (mm) | 38.10 |
Free Length (Decimal Inch) | 1-1/2 |
Outside Diameter (mm) | 16.51 |
Outside Diameter (Decimal Inch) | 0.6500 |
Maximum Work Load (N) | 44.93000031 |
Maximum Extended Length (mm) | 56.13 |
Maximum Extended Length (Decimal Inch) | 2.2100 |
