Associated Spring Raymond - 16.51mm OD, 73.36 N Max Load, 115.57mm Max Ext Len, Stainless Steel Extension Spring - 7.33 Lb/In Rating, 1.58 Lb Init Tension, 63.5mm Free Length
Item #: 69111367
Brand: Associated Spring Raymond
Model #: E06500692500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Stainless Steel |
| Spring Rate Pounds per Inch (Pounds) | 7.3300 |
| Initial Tension (N) | 7.03999996 |
| Initial Tension (Lb.) | 1.58000004 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Outside Diameter (mm) | 16.51 |
| Outside Diameter (Decimal Inch) | 0.6500 |
| Maximum Work Load (N) | 73.36000061 |
| Maximum Extended Length (mm) | 115.57 |
| Maximum Extended Length (Decimal Inch) | 4.5500 |
