Associated Spring Raymond - 25.4mm OD, 187.94 N Max Load, 183.9mm Max Ext Len, Music Wire Extension Spring - 11.9 Lb/In Rating, 3.8 Lb Init Tension, 101.6mm Free Length
Item #: 69109304
Brand: Associated Spring Raymond
Model #: E10001054000M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 11.9000 |
Initial Tension (N) | 16.89999962 |
Initial Tension (Lb.) | 3.79999995 |
Free Length (mm) | 101.60 |
Free Length (Decimal Inch) | 4 |
Outside Diameter (mm) | 25.40 |
Outside Diameter (Decimal Inch) | 1 |
Maximum Work Load (N) | 187.94000244 |
Maximum Extended Length (mm) | 183.90 |
Maximum Extended Length (Decimal Inch) | 7.2400 |
