Associated Spring Raymond - 31.75mm OD, 195.86 N Max Load, 301.24mm Max Ext Len, Music Wire Extension Spring - 6.3 Lb/In Rating, 3.96 Lb Init Tension, 139.7mm Free Length
Item #: 69108132
Brand: Associated Spring Raymond
Model #: E12501155500M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 6.3000 |
Initial Tension (N) | 17.61000061 |
Initial Tension (Lb.) | 3.96000004 |
Free Length (mm) | 139.70 |
Free Length (Decimal Inch) | 5-1/2 |
Outside Diameter (mm) | 31-3/4 |
Outside Diameter (Decimal Inch) | 1-1/4 |
Maximum Work Load (N) | 195.86000061 |
Maximum Extended Length (mm) | 301.24 |
Maximum Extended Length (Decimal Inch) | 11.8600 |
