Associated Spring Raymond - 7.62mm OD, 32.03 N Max Load, 60.2mm Max Ext Len, Music Wire Extension Spring - 6.6 Lb/In Rating, 0.65 Lb Init Tension, 34.8mm Free Length
Item #: 69105724
Brand: Associated Spring Raymond
Model #: E03000371370M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 6.6000 |
Initial Tension (N) | 2.89000010 |
Initial Tension (Lb.) | 0.64999998 |
Free Length (mm) | 34.80 |
Free Length (Decimal Inch) | 1.3700 |
Outside Diameter (mm) | 7.62 |
Outside Diameter (Decimal Inch) | 0.3000 |
Maximum Work Load (N) | 32.02999878 |
Maximum Extended Length (mm) | 60.20 |
Maximum Extended Length (Decimal Inch) | 2.3700 |
