![Associated Spring Raymond - 6.1mm OD, 27.74 N Max Load, 79.76mm Max Ext Len, Stainless Steel Extension Spring - 8.3 Lb/In Rating, 0.87 Lb Init Tension, 63.5mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909855-21_e2155d31-2064-4362-b29f-3e688220569c_1024x1024.jpg?v=1586245592)
Associated Spring Raymond - 6.1mm OD, 27.74 N Max Load, 79.76mm Max Ext Len, Stainless Steel Extension Spring - 8.3 Lb/In Rating, 0.87 Lb Init Tension, 63.5mm Free Length
Item #: 69105328
Brand: Associated Spring Raymond
Model #: E02400412500X
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 8.3000 |
Initial Tension (N) | 0.19599999 |
Initial Tension (Lb.) | 0.87000000 |
Free Length (mm) | 63-1/2 |
Free Length (Decimal Inch) | 2-1/2 |
Outside Diameter (mm) | 6.10 |
Outside Diameter (Decimal Inch) | 0.2400 |
Maximum Work Load (N) | 27.73999977 |
Maximum Extended Length (mm) | 79.76 |
Maximum Extended Length (Decimal Inch) | 3.1400 |
