Associated Spring Raymond - 6.1mm OD, 23.58 N Max Load, 105.66mm Max Ext Len, Music Wire Extension Spring - 2.5 Lb/In Rating, 0.5 Lb Init Tension, 57.15mm Free Length
Item #: 69104461
Brand: Associated Spring Raymond
Model #: E02400312250M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Music Wire |
| Spring Rate Pounds per Inch (Pounds) | 2.5000 |
| Initial Tension (N) | 2.22000003 |
| Initial Tension (Lb.) | 1/2 |
| Free Length (mm) | 57.15 |
| Free Length (Decimal Inch) | 2-1/4 |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Maximum Work Load (N) | 23.57999992 |
| Maximum Extended Length (mm) | 105.66 |
| Maximum Extended Length (Decimal Inch) | 4.1600 |
