Associated Spring Raymond - 6.1mm OD, 14.68 N Max Load, 222.5mm Max Ext Len, Music Wire Extension Spring - 0.6 Lb/In Rating, 0.3 Lb Init Tension, 88.9mm Free Length
Item #: 69103828
Brand: Associated Spring Raymond
Model #: E02400263500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Music Wire |
| Spring Rate Pounds per Inch (Pounds) | 0.6000 |
| Initial Tension (N) | 1.33000004 |
| Initial Tension (Lb.) | 0.30000001 |
| Free Length (mm) | 88.90 |
| Free Length (Decimal Inch) | 3-1/2 |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Maximum Work Load (N) | 14.68000031 |
| Maximum Extended Length (mm) | 222-1/2 |
| Maximum Extended Length (Decimal Inch) | 8.7600 |
