Associated Spring Raymond - 6.1mm OD, 7.67 N Max Load, 26.92mm Max Ext Len, Stainless Steel Extension Spring - 3.58 Lb/In Rating, 0.16 Lb Init Tension, 15.75mm Free Length
Item #: 69103299
Brand: Associated Spring Raymond
Model #: E02400220620S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 3.5800 |
Initial Tension (N) | 0.70999998 |
Initial Tension (Lb.) | 0.16000000 |
Free Length (mm) | 15-3/4 |
Free Length (Decimal Inch) | 0.6200 |
Outside Diameter (mm) | 6.10 |
Outside Diameter (Decimal Inch) | 0.2400 |
Maximum Work Load (N) | 7.67000008 |
Maximum Extended Length (mm) | 26.92 |
Maximum Extended Length (Decimal Inch) | 1.0600 |
