Associated Spring Raymond - 4.57mm OD, 21.8 N Max Load, 45.47mm Max Ext Len, Stainless Steel Extension Spring - 14.3 Lb/In Rating, 0.67 Lb Init Tension, 38.1mm Free Length
Item #: 69102994
Brand: Associated Spring Raymond
Model #: E01800341500X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Stainless Steel |
| Spring Rate Pounds per Inch (Pounds) | 14.3000 |
| Initial Tension (N) | 0.15099999 |
| Initial Tension (Lb.) | 0.67000002 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Maximum Work Load (N) | 21.79999924 |
| Maximum Extended Length (mm) | 45.47 |
| Maximum Extended Length (Decimal Inch) | 1.7900 |
