Associated Spring Raymond - 4.57mm OD, 15.56 N Max Load, 56.9mm Max Ext Len, Stainless Steel Extension Spring - 3.75 Lb/In Rating, 0.33 Lb Init Tension, 34.8mm Free Length
Item #: 69102192
Brand: Associated Spring Raymond
Model #: E01800261370S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 3.7500 |
Initial Tension (N) | 1.48000002 |
Initial Tension (Lb.) | 0.33000001 |
Free Length (mm) | 34.80 |
Free Length (Decimal Inch) | 1.3700 |
Outside Diameter (mm) | 4.57 |
Outside Diameter (Decimal Inch) | 0.1800 |
Maximum Work Load (N) | 15.56000042 |
Maximum Extended Length (mm) | 56.90 |
Maximum Extended Length (Decimal Inch) | 2.2400 |
