Associated Spring Raymond - 4.57mm OD, 12.79 N Max Load, 49.78mm Max Ext Len, Stainless Steel Extension Spring - 3.08 Lb/In Rating, 0.26 Lb Init Tension, 28.45mm Free Length
Item #: 69101863
Brand: Associated Spring Raymond
Model #: E01800241120S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Stainless Steel |
| Spring Rate Pounds per Inch (Pounds) | 3.0800 |
| Initial Tension (N) | 1.14999998 |
| Initial Tension (Lb.) | 0.25999999 |
| Free Length (mm) | 28.45 |
| Free Length (Decimal Inch) | 1.1200 |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Maximum Work Load (N) | 12.78999996 |
| Maximum Extended Length (mm) | 49.78 |
| Maximum Extended Length (Decimal Inch) | 1.9600 |
