Associated Spring Raymond - 4.57mm OD, 1.4 N Max Load, 28.7mm Max Ext Len, Stainless Steel Extension Spring - 0.5 Lb/In Rating, 0.06 Lb Init Tension, 15.75mm Free Length
Item #: 69100964
Brand: Associated Spring Raymond
Model #: E01800140620X
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 0.5000 |
Initial Tension (N) | 0.01300000 |
Initial Tension (Lb.) | 0.06000000 |
Free Length (mm) | 15-3/4 |
Free Length (Decimal Inch) | 0.6200 |
Outside Diameter (mm) | 4.57 |
Outside Diameter (Decimal Inch) | 0.1800 |
Maximum Work Load (N) | 1.39999998 |
Maximum Extended Length (mm) | 28.70 |
Maximum Extended Length (Decimal Inch) | 1.1300 |
