![Associated Spring Raymond - 2.39mm OD, 9.56 N Max Load, 33.78mm Max Ext Len, Music Wire Extension Spring - 4.4 Lb/In Rating, 0.19 Lb Init Tension, 22.35mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909853-21_5edbd711-5a3a-4dbf-bd3c-ac4680caf26e_1024x1024.jpg?v=1586719771)
Associated Spring Raymond - 2.39mm OD, 9.56 N Max Load, 33.78mm Max Ext Len, Music Wire Extension Spring - 4.4 Lb/In Rating, 0.19 Lb Init Tension, 22.35mm Free Length
Item #: 69099786
Brand: Associated Spring Raymond
Model #: E00940160880M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 4.4000 |
Initial Tension (N) | 0.85000002 |
Initial Tension (Lb.) | 0.19000000 |
Free Length (mm) | 22.35 |
Free Length (Decimal Inch) | 0.8800 |
Outside Diameter (mm) | 2.39 |
Outside Diameter (Decimal Inch) | 0.0940 |
Maximum Work Load (N) | 9.56000042 |
Maximum Extended Length (mm) | 33.78 |
Maximum Extended Length (Decimal Inch) | 1.3300 |
