Associated Spring Raymond - 2.39mm OD, 5.12 N Max Load, 47.24mm Max Ext Len, Music Wire Extension Spring - 1.2 Lb/In Rating, 0.1 Lb Init Tension, 25.4mm Free Length
Item #: 69099604
Brand: Associated Spring Raymond
Model #: E00940131000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Music Wire |
| Spring Rate Pounds per Inch (Pounds) | 1.2000 |
| Initial Tension (N) | 0.44000000 |
| Initial Tension (Lb.) | 0.10000000 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Outside Diameter (mm) | 2.39 |
| Outside Diameter (Decimal Inch) | 0.0940 |
| Maximum Work Load (N) | 5.11999989 |
| Maximum Extended Length (mm) | 47.24 |
| Maximum Extended Length (Decimal Inch) | 1.8600 |
