![Associated Spring Raymond - 1.6mm OD, 4.85 N Max Load, 8.64mm Max Ext Len, Music Wire Extension Spring - 11.1 Lb/In Rating, 0.1 Lb Init Tension, 6.35mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909853-21_d9b0258b-7d00-4a12-bf0b-56b8be40d541_1024x1024.jpg?v=1586245530)
Associated Spring Raymond - 1.6mm OD, 4.85 N Max Load, 8.64mm Max Ext Len, Music Wire Extension Spring - 11.1 Lb/In Rating, 0.1 Lb Init Tension, 6.35mm Free Length
Item #: 69098937
Brand: Associated Spring Raymond
Model #: E00630110250M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 11.1000 |
Initial Tension (N) | 0.44000000 |
Initial Tension (Lb.) | 0.10000000 |
Free Length (mm) | 6.35 |
Free Length (Decimal Inch) | 1/4 |
Outside Diameter (mm) | 1.60 |
Outside Diameter (Decimal Inch) | 0.0630 |
Maximum Work Load (N) | 4.84999990 |
Maximum Extended Length (mm) | 8.64 |
Maximum Extended Length (Decimal Inch) | 0.3400 |
