![Associated Spring Raymond - 4.57mm OD, 21.57 N Max Load, 36.32mm Max Ext Len, Stainless Steel Extension Spring - 10.16 Lb/In Rating, 0.43 Lb Init Tension, 25.4mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909855-21_9ecbb6c9-9fc1-428b-bf93-0bfc523e8750_1024x1024.jpg?v=1586589283)
Associated Spring Raymond - 4.57mm OD, 21.57 N Max Load, 36.32mm Max Ext Len, Stainless Steel Extension Spring - 10.16 Lb/In Rating, 0.43 Lb Init Tension, 25.4mm Free Length
Item #: 69095438
Brand: Associated Spring Raymond
Model #: E01800291000S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 10.1600 |
Initial Tension (N) | 1.91999996 |
Initial Tension (Lb.) | 0.43000001 |
Free Length (mm) | 25.40 |
Free Length (Decimal Inch) | 1 |
Outside Diameter (mm) | 4.57 |
Outside Diameter (Decimal Inch) | 0.1800 |
Maximum Work Load (N) | 21.56999969 |
Maximum Extended Length (mm) | 36.32 |
Maximum Extended Length (Decimal Inch) | 1.4300 |
