Associated Spring Raymond - 4.57mm OD, 33.24 N Max Load, 19.05mm Max Ext Len, Stainless Steel Extension Spring - 51.48 Lb/In Rating, 0.67 Lb Init Tension, 15.75mm Free Length
Item #: 69095222
Brand: Associated Spring Raymond
Model #: E01800340620S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Extension |
| Material | Stainless Steel |
| Spring Rate Pounds per Inch (Pounds) | 51.4800 |
| Initial Tension (N) | 3 |
| Initial Tension (Lb.) | 0.67000002 |
| Free Length (mm) | 15-3/4 |
| Free Length (Decimal Inch) | 0.6200 |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Maximum Work Load (N) | 33.24000168 |
| Maximum Extended Length (mm) | 19.05 |
| Maximum Extended Length (Decimal Inch) | 3/4 |
