![Associated Spring Raymond - 4.57mm OD, 33.24 N Max Load, 58.93mm Max Ext Len, Stainless Steel Extension Spring - 11.91 Lb/In Rating, 0.67 Lb Init Tension, 44.45mm Free Length - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/6909855-21_1788cf31-9cba-48c3-bed9-1ef614e3b2dd_1024x1024.jpg?v=1586245910)
Associated Spring Raymond - 4.57mm OD, 33.24 N Max Load, 58.93mm Max Ext Len, Stainless Steel Extension Spring - 11.91 Lb/In Rating, 0.67 Lb Init Tension, 44.45mm Free Length
Item #: 69095149
Brand: Associated Spring Raymond
Model #: E01800341750S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 11.9100 |
Initial Tension (N) | 3 |
Initial Tension (Lb.) | 0.67000002 |
Free Length (mm) | 44.45 |
Free Length (Decimal Inch) | 1-3/4 |
Outside Diameter (mm) | 4.57 |
Outside Diameter (Decimal Inch) | 0.1800 |
Maximum Work Load (N) | 33.24000168 |
Maximum Extended Length (mm) | 58.93 |
Maximum Extended Length (Decimal Inch) | 2.3200 |
