Associated Spring Raymond - 6.1mm OD, 16.68 N Max Load, 88.14mm Max Ext Len, Stainless Steel Extension Spring - 2 Lb/In Rating, 0.33 Lb Init Tension, 44.45mm Free Length
Item #: 69094589
Brand: Associated Spring Raymond
Model #: E02400291750S
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 2.0000 |
Initial Tension (N) | 1.48000002 |
Initial Tension (Lb.) | 0.33000001 |
Free Length (mm) | 44.45 |
Free Length (Decimal Inch) | 1-3/4 |
Outside Diameter (mm) | 6.10 |
Outside Diameter (Decimal Inch) | 0.2400 |
Maximum Work Load (N) | 16.68000031 |
Maximum Extended Length (mm) | 88.14 |
Maximum Extended Length (Decimal Inch) | 3.4700 |
