Associated Spring Raymond - 6.1mm OD, 31.14 N Max Load, 155.7mm Max Ext Len, Music Wire Extension Spring - 2.4 Lb/In Rating, 0.65 Lb Init Tension, 88.9mm Free Length
Item #: 69094019
Brand: Associated Spring Raymond
Model #: E02400343500M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 2.4000 |
Initial Tension (N) | 2.89000010 |
Initial Tension (Lb.) | 0.64999998 |
Free Length (mm) | 88.90 |
Free Length (Decimal Inch) | 3-1/2 |
Outside Diameter (mm) | 6.10 |
Outside Diameter (Decimal Inch) | 0.2400 |
Maximum Work Load (N) | 31.13999939 |
Maximum Extended Length (mm) | 155.70 |
Maximum Extended Length (Decimal Inch) | 6.1300 |
