Associated Spring Raymond - 6.1mm OD, 38.7 N Max Load, 183.39mm Max Ext Len, Music Wire Extension Spring - 2.9 Lb/In Rating, 0.8 Lb Init Tension, 114.3mm Free Length
Item #: 69093722
Brand: Associated Spring Raymond
Model #: E02400374500M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Music Wire |
Spring Rate Pounds per Inch (Pounds) | 2.9000 |
Initial Tension (N) | 3.55999994 |
Initial Tension (Lb.) | 0.80000001 |
Free Length (mm) | 114.30 |
Free Length (Decimal Inch) | 4-1/2 |
Outside Diameter (mm) | 6.10 |
Outside Diameter (Decimal Inch) | 0.2400 |
Maximum Work Load (N) | 38.70000076 |
Maximum Extended Length (mm) | 183.39 |
Maximum Extended Length (Decimal Inch) | 7.2200 |
