Associated Spring Raymond - 7.62mm OD, 9.06 N Max Load, 122.17mm Max Ext Len, Stainless Steel Extension Spring - 0.8 Lb/In Rating, 0.32 Lb Init Tension, 69.85mm Free Length
Item #: 69093433
Brand: Associated Spring Raymond
Model #: E03000312750X
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Extension |
Material | Stainless Steel |
Spring Rate Pounds per Inch (Pounds) | 0.8000 |
Initial Tension (N) | 0.07200000 |
Initial Tension (Lb.) | 0.31999999 |
Free Length (mm) | 69.85 |
Free Length (Decimal Inch) | 2-3/4 |
Outside Diameter (mm) | 7.62 |
Outside Diameter (Decimal Inch) | 0.3000 |
Maximum Work Load (N) | 9.06000042 |
Maximum Extended Length (mm) | 122.17 |
Maximum Extended Length (Decimal Inch) | 4.8100 |
