100mm Cut Diam, 1″ Arbor Hole Diam, 9mm Max Depth, Indexable Square-Shoulder Face Mill Takes 4 Inserts, 0/90° Lead Angle, 40mm High, AP..0903 Insert Style, Series Disc Cutter S
Item #: 68567239
Brand: OSG
Model #: 8070256
Product Specifications
| Maximum Cutting Diameter (Decimal Inch) | 3.9370 |
| Maximum Cutting Diameter (mm) | 100.00 |
| Maximum Depth of Cut (mm) | 9.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3543 |
| Arbor Hole Diameter (mm) | 25.40 |
| Arbor Hole Diameter (Inch) | 1 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Compatible Insert Size Code | AP..0903 |
| Insert Holding Method | Screw |
| Lead Angle | 0/90 |
| Series | Disc Cutter S |
| Overall Height (Mm - 5 Decimals) | 40.00 |
| Overall Height (Decimal Inch) | 1.5748 |
| Maximum RPM | 13400 |
| Number Of Cutter Inserts | 4 |
| Number Of Flutes | 4 |
