Abbott Workholding Products - 1.5mm x 60° Serrated Attachment, Square Soft Lathe Chuck Jaw - 3 Jaws, Aluminum, 1.1811" Btw Mount Hole Ctrs, 5-1/2" Long x 2" Wide x 6" High, 0.8268" Groove, 0.6299" & 16mm Fastener
Item #: 66154154
Brand: Abbott Workholding Products
Model #: KTTB212A6
Exact Tooling IR#: 04
Features and Benefits
Pointed jaws are blanks used for smaller part diameters, allowing closer contact than square end jaws.
| Product Specifications | |
|---|---|
| Jaw Type | Square |
| Material | Aluminum |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Maximum Compatible Chuck Diameter (Inch) | 12 |
| Maximum Compatible Chuck Diameter (Decimal Inch) | 12.0000 |
| Maximum Compatible Chuck Diameter (mm) | 304.80 |
| Overall Height (mm) | 152.40 |
| Overall Height (Inch) | 6 |
| Groove Width (mm) | 21.00 |
| Groove Width (Decimal Inch) | 0.8268 |
| Distance Between Mount Hole Centers (mm) | 30.00 |
| Distance Between Mount Hole Centers (Decimal Inch) | 1.1811 |
| Jaw End Shape | Pointed |
| Fastener Size (mm) | 16.00 |
| Fastener Size (Decimal Inch) | 0.6299 |
| Number of Jaws | 3 |
| Overall Width/Diameter (mm) | 50.80 |
| Overall Width/Diameter (Inch) | 2 |
| Overall Width/Diameter (Decimal Inch) | 2.0000 |
| Overall Length (Inch) | 5-1/2 |
| Overall Length (Decimal Inch) | 5.5000 |
| Overall Length (mm) | 139.70 |
| Material Grade | 6061-T6 |
