Indexable Square-Shoulder End Mill: 1SJ1F-1003780R01, 10.67 mm Max Depth of Cut, 1" Dia Weldon Flat Shank
Item #: 77929537
Brand: Ingersoll Cutting Tools
Model #: 3030467
Product Specifications
| Overall Length (Decimal Inch) | 6.0000 |
| Overall Length (mm) | 152.40 |
| Overall Length (Inch) | 6 |
| Maximum Depth of Cut (mm) | 10.67 |
| Maximum Depth of Cut (Decimal Inch) | 0.4200 |
| Cutter Style | 1SJ1F |
| Shank Type | Weldon Flat |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Shank Diameter (Inch) | 1 |
| Insert Holding Method | Screw |
| Maximum Ramping Angle | 0 |
| Tool Material | Steel |
| Series | 1SJ1F |
| Flute Type | Helical |
| Lead Angle | 90 |
| Shank Length (Decimal Inch) | 2.4100 |
| Shank Length (mm) | 61.21 |
| Head Length (Decimal Inch) | 3.59 |
| Head Length (mm) | 91.19 |
| Tool Application | Facing; Shouldering |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Rake | Negative |
| Complete Insert Compatibility | DGx314..; ZGx314.. |
| Insert Compatibility | DGx314..; ZGx314.. |
| Hand of Holder | Right Hand |
| Multi-Use Tool | Yes |
| UNSPSC Code | 27112803 |
| Manufacturers Catalog Number | 1SJ1F-1003780R01 |
| Usable Length (mm) | 91.19 |
| Number Of Flutes | 2 |
| Usable Length (Decimal Inch) | 3.5900 |
| Number Of Cutter Inserts | 2 |
| Coolant Through | Yes |
