9" x 42" Knee Milling Machine: 3 hp, Step Pulley, 3 Phase
Item #: 30391221
Brand: Enco
Model #: 5012961/3647447
Product Specifications
| Minimum Spindle to Column Distance (Decimal Inch) | 7.0000 |
| Minimum Spindle to Column Distance (Inch) | 7 |
| Minimum Spindle to Column Distance (mm) | 170.00 |
| Minimum Spindle to Table Distance (Decimal Inch) | 2.0000 |
| Minimum Spindle to Table Distance (mm) | 40.00 |
| Maximum Spindle to Table Distance (Inch) | 16.0000 |
| Maximum Spindle to Table Distance (mm) | 400.00 |
| Maximum Spindle to Table Distance (Decimal Inch) | 16.0000 |
| Minimum Spindle Speed | 80 |
| Table Length (Inch) | 42 |
| Table Width (Inch) | 9 |
| Maximum Spindle Speed | 5440 |
| Forward Head Tilt (Degrees) | 45 |
| Phase | Three |
| Backward Head Tilt (Degrees) | 45 |
| Left-Hand Head Tilt (Degrees) | 90 |
| Left-hand Head Tilt | 90 |
| Right-Hand Head Tilt (Degrees) | 90 |
| Right-hand Head Tilt | 90.0 |
| Cross Travel (Decimal Inch) | 12.0000 |
| Cross Travel | 12.0 in |
| Longitudinal Travel | 26.0 in |
| Longitudinal Travel (Decimal Inch) | 26.0000 |
| Knee Travel (Decimal Inch) | 14.0000 |
| Knee Travel | 14.0 in |
| Quill Diameter (Inch) | 3 |
| Quill Diameter (mm) | 85.73 |
| Quill Diameter (Decimal Inch) | 3.0000 |
| Horsepower | 3.00 |
| Voltage | 220V |
| Table Load Capacity (kg) | 250.00 |
| Table Load Capacity (Lb.) | 552.00 |
| Ram Turret Swivel (Degrees) | 360 |
| Ram Travel Length (Decimal Inch) | 12.0000 |
| Ram Travel Length (mm) | 310.00 |
| Ram Travel Length (Inch) | 12 |
| Spindle Speed Control | Step Pulley |
| Spindle Taper Size | R8 |
| Spindle Travel Length (mm) | 127.00 |
| Spindle Travel Length (Decimal Inch) | 5.0000 |
| Spindle Travel Length (Inch) | 5 |
| Number Of T-slots | 3 |
| Number of Spindle Speeds | 16 |
| Overall Height (Decimal Inch) | 79.0000 |
| Overall Height (Mm - 5 Decimals) | 2006.00 |
| Overall Height (Inch) | 79 |
| Overall Length (Inch) | 58 |
| Overall Length (Decimal Inch) | 58.0000 |
| Overall Length (mm) | 1478.00 |
| UNSPSC Code | 23242503 |
| Overall Depth (Decimal Inch) | 55.0000 |
| Overall Depth (Inch) | 55 |
| Overall Depth (Mm) | 1405.00 |
| Includes | 12 x 30 in 3-Axis DP500 Mill System with Bracket; Includes X-Axis 1-32 in/min Speed Mill Power Feed |
| Maximum Spindle To Column Distance (mm) | 480.00 |
| Maximum Spindle To Column Distance (Decimal Inch) | 19.0000 |
| Maximum Spindle To Column Distance (Inch) | 19 |
