Ball End Mill: 0.3150" Dia, 20.00 mm LOC, 4 Flute, Solid Carbide
Item #: 71914618
Brand: M.A. Ford
Model #: 14031500A
Product Specifications
| Mill Diameter (Decimal Inch) | 0.3150 |
| Number Of Flutes | 4 |
| End Mill Material | Solid Carbide |
| Length of Cut (mm) | 20.00 |
| Coating/Finish | AlTiN |
| Extended Reach | No |
| Variable Helix | No |
| Variable Index | No |
| Helix Angle | 30 |
| Overall Length (mm) | 64.00 |
| Chipbreaker | No |
| Undercutting | No |
| Length Of Cut Range (Decimal Inch) | 0.7000 - 1.0000 |
| Length Type | Standard |
| Shank Diameter (mm) | 8.00 |
| Nose Radius (mm) | 4.00 |
| Nose Radius (Decimal Inch) | 0.1575 |
| Mill Diameter Tolerance | +0.000/-0.058 mm |
| Maximum Helix Angle | 30 |
| Primary Workpiece Material Code | P; S; H; K; M; N |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Series | 140 |
| Flute Type | Spiral |
| UNSPSC Code | 27112803 |
| Single Or Double End | Single |
| Coolant Through | No |
| Length Of Cut (Decimal Inch - 4 Decimals) | 0.7874 |
| Mill Diameter (Decimal Inch) | 0.3150 |
| Number Of Flutes | 4 |
| End Mill Material | Solid Carbide |
| Length of Cut (mm) | 20.00 |
| Coating/Finish | AlTiN |
| Extended Reach | No |
| Variable Helix | No |
| Variable Index | No |
| Helix Angle | 30 |
| Overall Length (mm) | 64.00 |
| Chipbreaker | No |
| Undercutting | No |
| Length Of Cut Range (Decimal Inch) | 0.7000 - 1.0000 |
| Length Type | Standard |
| Shank Diameter (mm) | 8.00 |
| Nose Radius (mm) | 4.00 |
| Nose Radius (Decimal Inch) | 0.1575 |
| Mill Diameter Tolerance | +0.000/-0.058 mm |
| Maximum Helix Angle | 30 |
| Primary Workpiece Material Code | P; S; H; K; M; N |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Series | 140 |
| Flute Type | Spiral |
| UNSPSC Code | 27112803 |
| Single Or Double End | Single |
| Coolant Through | No |
| Length Of Cut (Decimal Inch - 4 Decimals) | 0.7874 |
| MSC Part # | 71914618 |
| Mfr Part # | 14031500A |
| Country of Origin Country of Origin is subject to change | UNITED STATES |
