Brand: Ingersoll Cutting Tools / Part #: 2923681

Brand: Ingersoll Cutting Tools / Part #: 2923681


Item #: 96670674
Brand: Ingersoll Cutting Tools
Model #: 2923681

Product Specifications

Minimum Cutting Diameter (Decimal Inch) 3.0000
Minimum Cutting Diameter (Inch) 3
Minimum Cutting Diameter (mm) 76.20
Maximum Cutting Diameter (Inch) 3
Maximum Cutting Diameter (Decimal Inch) 3.0000
Maximum Depth of Cut (Decimal Inch) 2.8900
Arbor Hole Diameter (Decimal Inch) 1.2500
Compatible Insert Size Code 324
Cutter Style 2XJ3J
Cutting Direction Right Hand
Insert Holding Method Screw
Lead Angle 90 deg
Rake Negative
Series 2XJ3J
Maximum Body Diameter (mm) 73.15
Maximum Body Diameter (Decimal Inch) 2.8800
Overall Height (Inch) 3-3/4
Overall Height (Decimal Inch) 3.7500
Keyway Width (Inch) 1/2
Keyway Width (Decimal Inch) 0.5000
Pitch Type Close
Tool Application Facing; Shouldering
Tool Performance General Purpose
Primary Workpiece Material Universal
Primary Workpiece Material Code O
Cutting Edge Length (Inch) 2-57/64
Cutting Edge Length (Decimal Inch) 2.8900
Complete Insert Compatibility IPM324?
Toolholder Material Steel
Manufacturers Catalog Number 2XJ3J-30037D4R02
Coolant Through Yes
Number Of Cutter Inserts 36
Number Of Flutes 6
$2,603.70
