50 Amp, 240 VAC, 3 Pole, DIN Rail Mounted, Flush Mount, Surface Mount Miniature Circuit Breaker Thermal Magnetic Trip, 10 kA at 120/240 VAC Breaking Capacity, 14-2 (Aluminum), 14-2 (Copper) AWG, 74mm Deep x 103mm High x 57mm Wide
Item #: 56788060
Brand: Square D
Model #: QOUR350
Product Specifications
| Circuit Breaker Type | Miniature Circuit Breaker |
| Milliamperage (mA) | 50.0000; 50 |
| Number of Poles | 3 |
| Breaking Capacity | 10 kA |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Lug |
| Mounting Type | DIN Rail Mounted; Flush Mount; Surface Mount |
| Voltage | 240.00 |
| Wire Size (sq mm) | 14.000 |
| Overall Depth | 74.00 mm; 2.9800 in |
| Overall Height | 4.0500 in; 103.00 mm |
| Maximum Operating Temperature (F) | 104 |
| Minimum Operating Temperature (F) | 14 |
| Overall Depth (mm) | 74 |
| Overall Depth (Inch) | 74.00 mm; 2.9800 in |
| Overall Height (mm) | 103 |
| Overall Height (Inch) | 4.0500 in; 103.00 mm |
| Overall Width (Decimal Inch) | 2-1/4 |
| For Use With | I-Line Panelboards & Switchboards |
| Standards Met | UL Listed; CCC; Federal Specification W-C 375 b/Gen; CSA Certified |
| Reset Actuator Type | Toggle Switch |
