Scientific Cutting Tools - 3/8-24" Port, 0.76" Spotface Diam, 3/16" Tube Outside Diam, Reamer Pilot, Carbide Tipped Porting Tool
Item #: 44065084
Brand: Scientific Cutting Tools
Model #: MS16142-3RC
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
Product Specifications | |
---|---|
Port Standard Designation | MS 16142; SAE J1926; SAE J514 |
Pilot Type | Reamer |
Port Thread Size (Decimal Inch) | 0.3750-24 |
Port Thread Size (Inch) | 3/8-24 |
Tool Material | Carbide-Tipped |
Tube Dash Number | 3.000 |
Tube Outside Diameter Compatibility (Decimal Inch) | 0.188 |
Tube Outside Diameter Compatibility (Inch) | 3/16 |
Minimum Pilot Diameter (Decimal Inch) | 0.3330 |
Maximum Pilot Diameter (Decimal Inch) | 0.4235 |
Spotface Diameter (Decimal Inch) | 0.7600 |
Pilot Length (Decimal Inch) | 0.3970 |
Identification Groove | No |
Workpiece Compatibility | Tubes |
Finish/Coating | TiN |
Head Length (Decimal Inch) | 1.2500 |
Overall Length (Decimal Inch) | 3.0000 |
Shank Diameter (Decimal Inch) | 0.5000 |
Shank Length (Decimal Inch) | 1.7500 |
Seal Angle | 12 |
Thread Type | UNF |
Flute Type | Straight |
Number of Flutes | 3 |
