Sandvik Coromant - AF151.37, Internal, Right Hand, 6.3mm Max Depth of Cut, 6mm Max Groove Width, Indexable Grooving Tool Holder - 151.3 Insert Compatibility, 1.4567" Shank Height, 11.811" OAL, Through Coolant
Item #: 54935119
Brand: Sandvik Coromant
Model #: 5738690
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Internal or External | Internal |
Toolholder Type | Face Grooving |
Hand of Holder | Right Hand |
Maximum Depth of Cut (Decimal Inch) | 0.2480 |
Maximum Depth of Cut (mm) | 6.30 |
Maximum Groove Width (mm) | 6.00 |
Maximum Groove Width (Decimal Inch) | 0.2362 |
Overall Length (Decimal Inch) | 11.8110 |
Toolholder Style | AF151.37 |
Insert Compatibility | 151.3 |
Shank Height (Decimal Inch) | 1.4567 |
Series | T-Max Q-Cut |
Through Coolant | Coolant Through |
Multi-Use Tool | Yes |
Multi-Use Application | Facing; Parting |
Insert Holding Method | Screw |
Insert Seat Size | 50 |
Minimum Hole Diameter (Decimal Inch) | 1.6535 |
Maximum Hole Depth (Decimal Inch) | 1.9685 |
Maximum Bore Depth (Decimal Inch) | 1.9685 |
igrvh Maximum Bore Depth (mm) | 50.00 |
Maximum Workpiece Diameter (Decimal Inch) | 15.7480 |
Maximum Groove Outside Diameter (mm) | 400.00 |
Minimum Axial Groove Inside Diameter(mm) | 23.00 |
Center to Cutting Edge (mm) | 20.80 |
Center to Cutting Edge (Decimal Inch) | 0.8189 |
Head Length (Decimal Inch) | 1.9685 |
Shank Length (Decimal Inch) | 9.8425 |
Manufacturers Catalog Number | RAF151.37-40-035A50 |
Height to Shank Top (Decimal Inch) | 1.4567 |
Toolholder Material | Steel |
Complete Insert Compatibility | N151.3-600-50-7G 1125; N151.3-600-50-7G 1145; N151.3-600-50-7G 2135; N151.3-600-50-7G 235; N151.3-600-50-7P 1125; N151.3-600-50-7P 2135; N151.3-600-50-7P 3115; N151.3-600-50-7P 4025; N151.3-600-50-7P 4125; N151.3-600-50-7P 4225 |
Minimum BoreDiameter (mm) | 42.00 |
Shank Diameter (Decimal Inch) | 1.5748 |
