Sandvik Coromant - B151.23, Internal, Left Hand, 1-1/2" Max Depth of Cut, Indexable Grooving Tool Holder - N151.2-A375-80-4G Insert Compatibility, 1-1/2" Shank Height, 1-1/2" Shank Width, 8-3/4" OAL
Item #: 54897798
Brand: Sandvik Coromant
Model #: 5735076
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | Internal |
| Toolholder Type | NonFace Grooving |
| Hand of Holder | Left Hand |
| Maximum Depth of Cut (Decimal Inch) | 1.4960 |
| Overall Length (Inch) | 8-3/4 |
| Overall Length (Decimal Inch) | 8.7500 |
| Toolholder Style | B151.23 |
| Insert Compatibility | N151.2-A375-80-4G |
| Shank Height (Decimal Inch) | 1.5000 |
| Shank Height (Inch) | 1-1/2 |
| Shank Width/Diameter (Inch) | 1-1/2 |
| Shank Width/Diameter (Decimal Inch) | 1.5000 |
| Series | T-Max Q-Cut |
| Through Coolant | Non Coolant Through |
| Multi-Use Tool | No |
| Insert Seat Size | 80 |
| Mount Type | 11 |
| Manufacturers Catalog Number | 5735076 |
| Toolholder Material | Steel |
| Complete Insert Compatibility | N151.2-A375-80-4G |
| Shank Diameter (Decimal Inch) | 1.5000 |
