Hubbell Wiring Device-Kellems - Pin & Sleeve Plugs & Connectors; Connector Type: Connector ; Pin Configuration: 5 ; Number of Poles: 4 ; Amperage: 100 ; Voltage: 120/208 VAC ; Maximum Cord Grip Diameter (mm): 49.30
Item #: 54033139
Brand: Hubbell Wiring Device-Kellems
Model #: HBL5100C9W
Product Specifications
Pin & Sleeve Plugs & Connectors; Connector Type: Connector ; Pin Configuration: 5 ; Number of Poles: 4 ; Amperage: 100 ; Voltage: 120/208 VAC ; Maximum Cord Grip Diameter (mm): 49.30
| Connector Type | Connector |
| Pin Configuration | 5 |
| Number of Poles | 4 |
| Amperage | 100 |
| Voltage | 120/208 VAC |
| Maximum Cord Grip Diameter (mm) | 49.30 |
| Maximum Cord Grip Diameter (Decimal Inch) | 1.9400 |
| Minimum Cord Grip Diameter (mm) | 27.10 |
| Minimum Cord Grip Diameter (Decimal Inch) | 1.0650 |
| Connector Diameter (mm) | 145 |
| Connector Diameter (Decimal Inch) | 5.7100 |
| Resistance Features | Impact Resistant; Moisture Resistant; Watertight |
| Color | Blue |
| Overall Length (mm) | 344.70 |
| Overall Length (Decimal Inch) | 13.5700 |
| Number of Phases | 3 |
| Ingress Protection Rating | IP67 |
| Material | Nylon |
| Standards Met | CSA C22.2 No. 182.1; CSA Certified; CSA File LR280C; IEC 60309-1; RoHS Compliant; UL 1682; UL 1686C2; UL File E146033; UL Listed |
