Hubbell Wiring Device-Kellems - Pin & Sleeve Plugs & Connectors; Connector Type: Plug ; Pin Configuration: 4 ; Number of Poles: 3 ; Amperage: 60 ; Voltage: 480 VAC ; Maximum Cord Grip Diameter (mm): 36.80 - Exact Industrial Supply

Hubbell Wiring Device-Kellems - Pin & Sleeve Plugs & Connectors; Connector Type: Plug ; Pin Configuration: 4 ; Number of Poles: 3 ; Amperage: 60 ; Voltage: 480 VAC ; Maximum Cord Grip Diameter (mm): 36.80


Item #: 54033097
Brand: Hubbell Wiring Device-Kellems
Model #: HBL460P7W

Product Specifications

Pin & Sleeve Plugs & Connectors; Connector Type: Plug ; Pin Configuration: 4 ; Number of Poles: 3 ; Amperage: 60 ; Voltage: 480 VAC ; Maximum Cord Grip Diameter (mm): 36.80
Connector Type Plug
Pin Configuration 4
Number of Poles 3
Amperage 60
Voltage 480 VAC
Maximum Cord Grip Diameter (mm) 36.80
Maximum Cord Grip Diameter (Decimal Inch) 1.4500
Minimum Cord Grip Diameter (mm) 12.70
Minimum Cord Grip Diameter (Decimal Inch) 1/2
Plug Diameter (mm) 114
Plug Diameter (Decimal Inch) 4.4900
Resistance Features Impact Resistant; Moisture Resistant; Watertight
Color Red
Overall Length (mm) 257.80
Overall Length (Decimal Inch) 10.1500
Number of Phases 3
Ingress Protection Rating IP67
Material Nylon
Standards Met CSA C22.2 No. 182.1; CSA Certified; CSA File LR280C; IEC 60309-1; RoHS Compliant; UL 1682; UL 1686C2; UL File E146033; UL Listed
$545.60

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
