Sumitomo - 160mm Cut Diam, 50.8mm Arbor Hole, 45° Indexable Chamfer & Angle Face Mill - 16 Inserts, SE.. 13T3\xB6XEEW 13T3 Insert, Right Hand Cut, Series WaveMill
Item #: 53966339
Brand: Sumitomo
Model #: 2200189
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 160.00 |
| Cutting Diameter (Decimal Inch) | 6.2992 |
| Arbor Hole Diameter (mm) | 50.80 |
| Arbor Hole Diameter (Decimal Inch) | 2.0000 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 2.4803 |
| Overall Height (mm) | 63.00 |
| Insert Compatibility | SE.. 13T3; XEEW 13T3 |
| Series | WaveMill |
| Through Coolant | No |
| Number of Cutter Inserts | 16 |
| Insert Holding Method | Screw |
| Cutter Style | WGCF |
| Hub Diameter (Decimal Inch) | 3.9370 |
| Hub Diameter (mm) | 100.00 |
| Keyway Width (mm) | 19.00 |
| Keyway Width (Decimal Inch) | 0.7480 |
| Maximum Body Diameter (Decimal Inch) | 6.8110 |
| Cutting Direction | Right Hand |
| Pitch | Fine |
| Complete Insert Compatibility | SECW 13T3AG; SEET 13T3AG; SEMT 13T3AG; XEEW 13T3AG |
