![Sumitomo - 19.99mm Min Bore Diam, 7" OAL, 16mm Shank Diam, BNB Indexable Boring Bar - TBGE 52 Insert, Clamp Holding Method - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/5394808-21_5102e749-df35-4daf-988f-01a2e53bcebb_1024x1024.jpg?v=1585782405)
Sumitomo - 19.99mm Min Bore Diam, 7" OAL, 16mm Shank Diam, BNB Indexable Boring Bar - TBGE 52 Insert, Clamp Holding Method
Item #: 53948089
Brand: Sumitomo
Model #: 5900053
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Toolholder Style | BNB |
Minimum Bore Diameter (mm) | 19.99 |
Minimum Bore Diameter (Decimal Inch) | 0.7870 |
Hand of Holder | Right Hand |
Overall Length (mm) | 177.80 |
Overall Length (Inch) | 7 |
Shank Diameter (mm) | 16.00 |
Shank Diameter (Decimal Inch) | 0.6300 |
Insert Compatibility | TBGE 52 |
Through Coolant | Yes |
Multi-Use Tool | No |
Insert Holding Method | Clamp |
Rake | Negative |
Lead Angle | 2 |
Insert Thickness (Inch) | 1/8 |
Insert Thickness (Decimal Inch) | 0.1250 |
Insert Inscribed Circle (Inch) | 5/32 |
Insert Inscribed Circle (Decimal Inch) | 0.1563 |
Rake Angle | -5 |
Coolant Hole Diameter (mm) | 5.00 |
Coolant Hole Diameter (Decimal Inch) | 0.1969 |
Complete Insert Compatibility | TBGE 52 |
Toolholder Material | Carbide |
