Walter - Arbor Hole Connection, 0.0787" Cutting Width, 0.7874" Depth of Cut, 80mm Cutter Diam, 0.6299" Hole Diam, 7 Tooth Indexable Slotting Cutter - F5055.B Toolholder, SX-2E Insert, Right Hand Cutting Direction
Item #: 53078242
Brand: Walter
Model #: 6412678
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 2.00 |
| Cutting Width (Decimal Inch) | 0.0787 |
| Maximum Depth of Cut (mm) | 20.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.7874 |
| Cutter Diameter (mm) | 80.00 |
| Cutter Diameter (Decimal Inch) | 3.1496 |
| Hole Diameter (mm) | 16.00 |
| Hole Diameter (Decimal Inch) | 0.6299 |
| Number of Teeth | 7 |
| Toolholder Style | F5055.B |
| Series | Blaxx |
| Insert Style | SX-2E |
| Staggered Tooth | No |
| Number of Cutter Inserts | 7 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Keyway Width (Decimal Inch) | 0.1575 |
| Keyway Width (mm) | 4.00 |
| Radius | No |
| Cutter Body Width (mm) | 1.60 |
| Cutter Body Width (Decimal Inch) | 0.0630 |
| Manufacturers Catalog Number | F5055.B16.080.Z07.2,0 |
| Complete Insert Compatibility1 | SX-2E200N02-CE4; SX-2E200N02-CF5; SX-2E200N02-CF6 |
