Walter - NCAI, Internal, Left Hand, 3/4" Max Depth of Cut, 0.236" Max Groove Width, Indexable Grooving Tool Holder - GX24-4.. Insert Compatibility, 1-1/2" Shank Width, 5.835" OAL, Through Coolant
Item #: 53005039
Brand: Walter
Model #: 5029119
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Internal or External | Internal |
Toolholder Type | NonFace Grooving |
Hand of Holder | Left Hand |
Maximum Depth of Cut (Decimal Inch) | 0.7480 |
Minimum Groove Width (Decimal Inch) | 0.2360 |
Maximum Groove Width (Decimal Inch) | 0.2360 |
Overall Length (Decimal Inch) | 5.8350 |
Toolholder Style | NCAI |
Insert Compatibility | GX24-4.. |
Shank Width/Diameter (Decimal Inch) | 1.5000 |
Through Coolant | Coolant Through |
Multi-Use Tool | Yes |
Multi-Use Application | Threading; Turning |
Insert Holding Method | Self Clamp |
Minimum Hole Diameter (Decimal Inch) | 2.3620 |
Center to Cutting Edge (Decimal Inch) | 1.4170 |
Head Height (Decimal Inch) | 1.9690 |
Head Length (Decimal Inch) | 2.3620 |
Full Radius Insert | Yes |
Shank Length (Decimal Inch) | 3.0000 |
Complete Insert Compatibility | GX24-4E600N030-CE4; GX24-4E600N03-CE4; GX24-4E600N050-GD3; GX24-4E600N050-UA4; GX24-4E600N050-UF4; GX24-4E600N05-GD3; GX24-4E600N05-GD6; GX24-4E600N05-UD6; GX24-4E600N05-UF4; GX24-4E600N080-UF4; GX24-4E600N08-UF4; GX24-4E600N300-RD4; GX24-4E600N30-RD4 |
