Walter - NCCI, Internal, Left Hand, 3mm Max Depth of Cut, 0.6 to 2.3mm Groove Width, Indexable Grooving Tool Holder - GX16-2.. Insert Compatibility, 50mm Shank Width, 350.2mm OAL, Through Coolant
Item #: 53004164
Brand: Walter
Model #: 5009518
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Internal or External | Internal |
Toolholder Type | NonFace Grooving |
Hand of Holder | Left Hand |
Maximum Depth of Cut (Decimal Inch) | 0.1181 |
Maximum Depth of Cut (mm) | 3.00 |
Minimum Groove Width (Decimal Inch) | 0.0236 |
Minimum Groove Width (mm) | 0.60 |
Maximum Groove Width (mm) | 2.30 |
Maximum Groove Width (Decimal Inch) | 0.0906 |
Overall Length (mm) | 350.20 |
Overall Length (Decimal Inch) | 13.7874 |
Toolholder Style | NCCI |
Insert Compatibility | GX16-2.. |
Shank Width/Diameter (mm) | 50.00 |
Shank Width/Diameter (Decimal Inch) | 1.9685 |
Through Coolant | Coolant Through |
Multi-Use Tool | Yes |
Multi-Use Application | Threading |
Insert Holding Method | Self Clamp |
Minimum Hole Diameter (mm) | 50.00 |
Minimum Hole Diameter (Decimal Inch) | 1.9685 |
Center to Cutting Edge (mm) | 35.50 |
Center to Cutting Edge (Decimal Inch) | 1.3976 |
Head Length (mm) | 99.00 |
Head Length (Decimal Inch) | 3.8976 |
Full Radius Insert | No |
Shank Length (mm) | 251.20 |
Shank Length (Decimal Inch) | 9.8898 |
Complete Insert Compatibility | GX16-2E300N02-CE4; GX16-2E300N02-CF5; GX16-2E300N02-CF6; GX16-2E300N030-GD3; GX16-2E300N030-UA4; GX16-2E300N030-UF4; GX16-2E300N03-GD3; GX16-2E300N03-GD6; GX16-2E300N03-UD6; GX16-2E300N03-UF4; GX16-2E300R/L6-CE4; GX16-2E300R/L6-CF5; GX16-2E300R/L6-CF6; GX |
