![Walter - NCAI, Internal, Right Hand, 10mm Max Depth of Cut, 6 to 6mm Groove Width, Indexable Grooving Tool Holder - GX16-4E.. Insert Compatibility, 50mm Shank Width, 350.9mm OAL, Through Coolant - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3708924-21_d315c2ea-c440-483c-99ca-407b32a6e258_1024x1024.jpg?v=1585812265)
Walter - NCAI, Internal, Right Hand, 10mm Max Depth of Cut, 6 to 6mm Groove Width, Indexable Grooving Tool Holder - GX16-4E.. Insert Compatibility, 50mm Shank Width, 350.9mm OAL, Through Coolant
Item #: 53004065
Brand: Walter
Model #: 5009499
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Internal or External | Internal |
Toolholder Type | NonFace Grooving |
Hand of Holder | Right Hand |
Maximum Depth of Cut (Decimal Inch) | 0.3937 |
Maximum Depth of Cut (mm) | 10.00 |
Minimum Groove Width (Decimal Inch) | 0.2362 |
Minimum Groove Width (mm) | 6.00 |
Maximum Groove Width (mm) | 6.00 |
Maximum Groove Width (Decimal Inch) | 0.2362 |
Overall Length (mm) | 350.90 |
Overall Length (Decimal Inch) | 13.8150 |
Toolholder Style | NCAI |
Insert Compatibility | GX16-4E.. |
Shank Width/Diameter (mm) | 50.00 |
Shank Width/Diameter (Decimal Inch) | 1.9685 |
Through Coolant | Coolant Through |
Multi-Use Tool | Yes |
Multi-Use Application | Threading; Turning |
Insert Holding Method | Self Clamp |
Minimum Hole Diameter (mm) | 50.00 |
Minimum Hole Diameter (Decimal Inch) | 1.9685 |
Center to Cutting Edge (mm) | 35.50 |
Center to Cutting Edge (Decimal Inch) | 1.3976 |
Head Height (Decimal Inch) | 1.9685 |
Head Height (mm) | 50.00 |
Head Length (mm) | 97.90 |
Head Length (Decimal Inch) | 3.8543 |
Full Radius Insert | No |
Shank Length (mm) | 253.00 |
Shank Length (Decimal Inch) | 9.9606 |
Complete Insert Compatibility | GX16-4E600N050-UA4; GX16-4E600N050-UF4; GX16-4E600N05-GD3; GX16-4E600N05-GD6; GX16-4E600N05-UD6; GX16-4E600N05-UF4; GX16-4E8.30N |
