Walter - NCAI, Internal, Left Hand, 10mm Max Depth of Cut, 2 to 2.5mm Groove Width, Indexable Grooving Tool Holder - GX16-1E.. Insert Compatibility, 50mm Shank Width, 350.7mm OAL, Through Coolant
Item #: 53004032
Brand: Walter
Model #: 5009491
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Internal or External | Internal |
Toolholder Type | NonFace Grooving |
Hand of Holder | Left Hand |
Maximum Depth of Cut (Decimal Inch) | 0.3937 |
Maximum Depth of Cut (mm) | 10.00 |
Minimum Groove Width (Decimal Inch) | 0.0787 |
Minimum Groove Width (mm) | 2.00 |
Maximum Groove Width (mm) | 2.50 |
Maximum Groove Width (Decimal Inch) | 0.0984 |
Overall Length (mm) | 350.70 |
Overall Length (Decimal Inch) | 13.8071 |
Toolholder Style | NCAI |
Insert Compatibility | GX16-1E.. |
Shank Width/Diameter (mm) | 50.00 |
Shank Width/Diameter (Decimal Inch) | 1.9685 |
Through Coolant | Coolant Through |
Multi-Use Tool | Yes |
Multi-Use Application | Threading; Turning |
Insert Holding Method | Self Clamp |
Minimum Hole Diameter (mm) | 50.00 |
Minimum Hole Diameter (Decimal Inch) | 1.9685 |
Center to Cutting Edge (mm) | 35.50 |
Center to Cutting Edge (Decimal Inch) | 1.3976 |
Head Height (Decimal Inch) | 1.9685 |
Head Height (mm) | 50.00 |
Head Length (mm) | 99.40 |
Head Length (Decimal Inch) | 3.9134 |
Full Radius Insert | No |
Shank Length (mm) | 251.30 |
Shank Length (Decimal Inch) | 9.8937 |
Complete Insert Compatibility | GX16-1E200N020-CF6; GX16-1E200N020-GD3; GX16-1E200N020-UA4; GX16-1E200N020-UF4; GX16-1E200N02-CE4; GX16-1E200N02-CF5; GX16-1E200N02-CF6; GX16-1E200N02-GD3; GX16-1E200N02-GD6; GX16-1E200N02-UD6; GX16-1E200N02-UF4; GX16-1E200N10-RD4; GX16-1E200R/L6-CE4 |
