![Walter - NCAI, Internal, Left Hand, 19mm Max Depth of Cut, 6 to 6mm Groove Width, Indexable Grooving Tool Holder - GX24-4E.. Insert Compatibility, 40mm Shank Width, 130mm OAL, Through Coolant - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3708924-21_6c29e1c0-a355-401d-a2de-0d0e04f7e1e9_1024x1024.jpg?v=1585639789)
Walter - NCAI, Internal, Left Hand, 19mm Max Depth of Cut, 6 to 6mm Groove Width, Indexable Grooving Tool Holder - GX24-4E.. Insert Compatibility, 40mm Shank Width, 130mm OAL, Through Coolant
Item #: 52999067
Brand: Walter
Model #: 5009550
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Internal or External | Internal |
Toolholder Type | NonFace Grooving |
Hand of Holder | Left Hand |
Maximum Depth of Cut (Decimal Inch) | 0.7480 |
Maximum Depth of Cut (mm) | 19.00 |
Minimum Groove Width (Decimal Inch) | 0.2362 |
Minimum Groove Width (mm) | 6.00 |
Maximum Groove Width (mm) | 6.00 |
Maximum Groove Width (Decimal Inch) | 0.2362 |
Overall Length (mm) | 130.00 |
Overall Length (Decimal Inch) | 5.1181 |
Toolholder Style | NCAI |
Insert Compatibility | GX24-4E.. |
Shank Width/Diameter (mm) | 40.00 |
Shank Width/Diameter (Decimal Inch) | 1.5748 |
Through Coolant | Coolant Through |
Multi-Use Tool | Yes |
Multi-Use Application | Threading; Turning |
Insert Holding Method | Self Clamp |
Minimum Hole Diameter (mm) | 60.00 |
Minimum Hole Diameter (Decimal Inch) | 2.3622 |
Center to Cutting Edge (mm) | 36.00 |
Center to Cutting Edge (Decimal Inch) | 1.4173 |
Head Height (Decimal Inch) | 1.9685 |
Head Height (mm) | 50.00 |
Head Length (mm) | 58.20 |
Head Length (Decimal Inch) | 2.2913 |
Full Radius Insert | No |
Shank Length (mm) | 70.00 |
Shank Length (Decimal Inch) | 2.7559 |
Complete Insert Compatibility | GX24-4E600N030-CE4; GX24-4E600N03-CE4; GX24-4E600N050-GD3; GX24-4E600N050-UA4; GX24-4E600N050-UF4; GX24-4E600N05-GD3; GX24-4E600N05-GD6; GX24-4E600N05-UD6; GX24-4E600N05-UF4; GX24-4E600N080-UF4; GX24-4E600N08-UF4; GX24-4E600N300-RD4; GX24-4E600N30-RD4 |
