Iscar - 25mm Cut Diam, 9.6mm Max Depth of Cut, 25mm Shank Diam, 95mm OAL, Indexable Square Shoulder End Mill - Weldon Shank, 90° Lead Angle, Series Heliquad
Item #: 52707999
Brand: Iscar
Model #: 3110437
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Cutting Diameter (mm) | 25.00 |
Cutting Diameter (Decimal Inch) | 0.9843 |
Shank Type | Weldon |
Shank Diameter (mm) | 25.00 |
Shank Diameter (Decimal Inch) | 0.9843 |
Overall Length/Projection (mm) | 95.00 |
Overall Length/Projection (Decimal Inch) | 3.7402 |
Lead Angle | 90 |
Series | Heliquad |
Through Coolant | Noncoolant Through |
Maximum Depth of Cut (mm) | 9.60 |
Maximum Depth of Cut (Decimal Inch) | 0.3780 |
Number of Cutter Inserts | 2 |
Insert Holding Method | Screw |
End Mill Type | End Mill |
Number of Flutes | 2 |
Head Length (mm) | 32.00 |
Head Length (Decimal Inch) | 1.2598 |
Weldon Flat | Yes |
Shank Length (Decimal Inch) | 2.4803 |
Shank Length (mm) | 63.00 |
