Kyocera - Internal Thread, Right Hand Cut, 16mm Shank Width x 14mm Shank Height Indexable Threading Toolholder - 150mm OAL, Various Insert Compatibility, SIN Toolholder
Item #: 50480227
Brand: Kyocera
Model #: 8806837
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Type | Internal |
| Hand of Holder | Right Hand |
| Shank Width/Diameter (mm) | 16.00 |
| Shank Width/Diameter (Decimal Inch) | 0.6299 |
| Shank Height (mm) | 14.00 |
| Shank Height (Decimal Inch) | 0.5512 |
| Overall Length (Decimal Inch) | 5.9055 |
| Overall Length (mm) | 150.00 |
| Insert Compatibility | 11IR/L 050ISO; 11IR/L 075ISO; 11IR/L 100ISO; 11IR/L 100ISO-TF; 11IR/L 125ISO; 11IR/L 125ISO-TF; 11IR/L 14BSPT; 11IR/L 14BSPT-TF; 11IR/L 14BSPT-TS; 11IR/L 150ISO; 11IR/L 150ISO-TF; 11IR/L 175ISO; 11IR/L 175ISO-TF; 11IR/L 19BSPT; 11IR/L 19BSPT-TF; 11IR/L 19 |
| Toolholder Style | SIN |
| Through Coolant | No |
| Multi-Use Tool | No |
| Insert Holding Method | Clamp |
| Center to Cutting Edge (mm) | 6.30 |
| Center to Cutting Edge (Decimal Inch) | 0.2480 |
| Head Length (mm) | 25.00 |
| Head Length (Decimal Inch) | 0.9843 |
| Shank Length (Decimal Inch) | 4.9213 |
| Minimum Bore Diameter (Decimal Inch) | 0.4724 |
| Insert Inscribed Circle (mm) | 6.35 |
| Insert Inscribed Circle (Decimal Inch) | 0.2500 |
| Shank Length (mm) | 125 |
| Minimum Bore Diameter (mm) | 12 |
