10mm Min Bore, 16mm Max Depth, Left Hand E(C)-STLB(P)-A Indexable Boring Bar 140mm OAL, 8mm Shank Diam, 5° Lead Angle, Uses TPGB 1815.., TPGH 1815.., TPMH 1815.., TPMT 1815.., E(C)-STLB(P)-A Inserts, Through Coolant
Item #: 50356914
Brand: Kyocera
Model #: THC13737
Product Specifications
| Minimum Bore Diameter (mm) | 10.00 |
| Minimum Bore Diameter (Decimal Inch) | 0.3937 |
| Maximum Bore Depth (Decimal Inch) | 0.6299 |
| Maximum Bore Depth (mm) | 16.00 |
| Toolholder Style | E(C)-STLB(P)-A |
| Tool Material | Solid Carbide |
| Insert Compatibility | TPGH 1815..; TPGB 1815..; TPMH 1815..; TPMT 1815.. |
| Shank Diameter (Decimal Inch) | 0.3150 |
| Shank Diameter (mm) | 8.00 |
| Hand of Holder | Left Hand |
| Overall Length (Decimal Inch) | 5.5118 |
| Overall Length (mm) | 140.00 |
| Compatible Insert Size Code | 1815 |
| Insert Holding Method | Screw |
| Compatible Insert Shape | Triangle |
| Rake | Negative |
| Cutting Direction | Left Hand |
| Rake Angle | -10.00 |
| Lead Angle | 5.00 |
| Series | Dynamic Bars |
| Insert Inscribed Circle (Inch) | 7/32 |
| Insert Inscribed Circle (Decimal Inch) | 0.2188 |
| Compatible Insert Thickness (mm) | 2.38 |
| Multi-use Tool | Yes |
| Cutting Tool Application | Facing; Boring |
| Center to Cutting Edge (Decimal Inch) | 0.1969 |
| Center to Cutting Edge (mm) | 5.00 |
| Multi-Use Application | Internal Facing |
| Number of Inserts Used on Toolholder | 1 |
| Insert Thickness (Decimal Inch) | 0.0938 |
| Insert Thickness (Inch) | 3/32 |
| Coolant Hole Diameter (Decimal Inch) | 0.1181 |
| Coolant Hole Diameter (mm) | 3.00 |
| Coolant Through | Yes |
 | |
| MSC Part # | 50356914 |
| Mfr Part # | THC13737 |
| Country of OriginCountry of Origin is subject to change | VARIOUS |
