Iscar - MM EC Grade IC308 Carbide End Milling Tip Insert - TiCN Finish, 5 Flutes, 20mm Cutting Diam, 15mm Depth of Cut, 25.5mm Extension
Item #: 50099019
Brand: Iscar
Model #: 5623384
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium carbonitride (TiCN) is harder and more wear resistant than TiN. It is commonly used on stainless steel, cast iron and aluminum alloys.
Product Specifications | |
---|---|
Series | Multimaster |
Milling Tip Style | MM EC |
Milling Tip Type | End Mill |
Material | Carbide |
Cutting Diameter (mm) | 20.00 |
Cutting Diameter (Decimal Inch) | 0.7874 |
Material Grade | Submicron |
Manufacturer's Grade | IC308 |
Depth of Cut (mm) | 15.00 |
Depth of Cut (Decimal Inch) | 0.5906 |
Number of Flutes | 5 |
Coating | TiCN |
Milling Tip Full Description | Roughing & Finishing End Mill |
Coating Process | PVD |
Extension From Holder (mm) | 25.50 |
Extension From Holder (Decimal Inch) | 1.0039 |
Thread Size | T12 |
