Schneider Electric - 1.22 Inch Mount Hole, 2 Position, Knob Operated, Selector Switch with Contact Blocks - Red, Maintained (MA), Illuminated, 1 Contact Block, NO/NC, Anticorrosive, Dusttight, Oiltight, Watertight, Shock and Vibration Resistant
Item #: 49896657
Brand: Schneider Electric
Model #: 9001SK11J35RH1
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Mounting Hole Diameter (mm) | 31 |
Mounting Hole Diameter (Decimal Inch) | 1.2200 |
Selector Switch Type | Selector Switch with Contact Blocks |
Operator Type | Knob |
Number of Positions | 2 |
Operation Type | Maintained (MA) |
Operator Color | Red |
Terminal Type | Screw Clamp |
Contact Configuration | NO/NC |
Voltage | 24-28 VAC/VDC (Light Module); 600 VAC/VDC |
Amperage | 10 |
Number of Contact Blocks | 1 |
Cam Code | E |
Operator Illumination | Illuminated |
Bezel Material | Plastic |
Bezel Color | Black |
Head Shape | Round |
Mounting Type | Panel Mount |
Mounting Orientation | Horizontal; Vertical |
Resistance Features | Anti-Corrosive; Dust-tight; Oiltight; Shock Resistant; Vibration Resistant; Watertight |
Ingress Protection Rating | IP20 (Terminal); IP65; IP66 |
NEMA Rating | 1; 2; 3; 4; 6; 12; 13; 3R; 4X |
Standards Met | CE Marked; CSA C22.2 No. 14; CSA File No. LR25490 Class 3211 03; CSA File No. LR26817 Class 3218 02; EN/IEC 60529; EN/IEC 60947-1; EN/IEC 60947-5-1; EN/IEC 60947-5-4; IEC 60068-2-27; IEC 60068-2-6; IEC 61140; JIS C 4520; JIS C 852; RoHS Compliant; UL 508 |
