Schneider Electric - 1.22 Inch Mount Hole, 2 Position, Knob Operated, Selector Switch with Contact Blocks - Black, Maintained (MA), Nonilluminated, 2 Contact Blocks, 2NO/2NC, Dust, Oil and Watertight
Item #: 49892599
Brand: Schneider Electric
Model #: 9001KXSAEBH2
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Mounting Hole Diameter (mm) | 31 |
| Mounting Hole Diameter (Decimal Inch) | 1.2200 |
| Selector Switch Type | Selector Switch with Contact Blocks |
| Operator Type | Knob |
| Number of Positions | 2 |
| Operation Type | Maintained (MA) |
| Operator Color | Black |
| Terminal Type | Screw Clamp |
| Contact Configuration | 2NO/2NC |
| Voltage | 600 VAC/VDC |
| Amperage | 10 |
| Number of Contact Blocks | 2 |
| Cam Code | E |
| Operator Illumination | NonIlluminated |
| Bezel Material | Zinc |
| Bezel Color | Chrome |
| Head Shape | Square |
| Mounting Type | Panel Mount |
| Mounting Orientation | Horizontal; Vertical |
| Resistance Features | Dust-tight; Oiltight; Watertight |
| Ingress Protection Rating | IP20 (Terminal); IP66 |
| NEMA Rating | 1; 2; 3; 4; 12; 13; 3R |
| Standards Met | CE Marked; CSA C22.2 No. 14; CSA File No. LR25490 Class 3211 03; EN/IEC 60529; EN/IEC 60947-1; EN/IEC 60947-5-1; RoHS Compliant; UL 508; UL File No. E42259 CCN NKCR; UL File No. E78403 CCN NKCR |
